Provide reliable temporary and emergency electricity with the XMSJ Open-Frame Diesel Generator range. Available in rated power options from 3 kW to 9 kW, these generators are designed for homes, farms, workshops, construction sites, commercial operations, and remote work locations.
Each model uses a single-cylinder, four-stroke, air-cooled diesel engine with direct fuel injection. The self-excited alternator, circuit protection, voltmeter, and oil-alert system support stable operation and convenient monitoring.
Manual starting is available as standard or according to the selected configuration, while electric start, automatic transfer switching, remote control, wheels, and digital meters are available as optional upgrades.
Key Features
-
Open-frame diesel generator range
-
Rated power options from 3 kW to 9 kW
-
Maximum output options from 3.5 kW to 10 kW
-
220 V output
-
50 Hz operating frequency
-
Single-phase or three-phase configurations
-
Manual or optional electric starting
-
Air-cooled four-stroke diesel engine
-
Direct-injection combustion system
-
Self-excited two-pole alternator
-
AC output socket
-
AC circuit breaker
-
Integrated voltmeter
-
Low-oil warning system
-
12 V DC output
-
Optional ATS and remote control
-
Twelve-month warranty
Available Models
DH3800
-
Rated Output: 3 kW
-
Maximum Output: 3.5 kW
-
Engine Displacement: 256 cc
-
Fuel Tank Capacity: 12.5 L
-
Continuous Runtime: Approximately 15 Hours
-
Net Weight: 71 kg
-
Dimensions: 690 × 490 × 560 mm
ODH6500
-
Rated Output: 5 kW
-
Maximum Output: 5.5 kW
-
Engine Displacement: 418 cc
-
Fuel Tank Capacity: 15 L
-
Continuous Runtime: Approximately 14 Hours
-
Net Weight: 105 kg
-
Dimensions: 740 × 530 × 635 mm
ODH8500
-
Rated Output: 6 kW
-
Maximum Output: 6.5 kW
-
Engine Displacement: 456 cc
-
Fuel Tank Capacity: 15 L
-
Continuous Runtime: Approximately 13 Hours
-
Net Weight: 108 kg
-
Dimensions: 740 × 530 × 635 mm
ODH9500
-
Rated Output: 7.5 kW
-
Maximum Output: 8 kW
-
Engine Displacement: 490 cc
-
Fuel Tank Capacity: 15 L
-
Continuous Runtime: Approximately 12 Hours
-
Net Weight: 110 kg
-
Dimensions: 740 × 530 × 635 mm
ODH10500
-
Rated Output: 9 kW
-
Maximum Output: 10 kW
-
Engine Displacement: 530 cc
-
Fuel Tank Capacity: 15 L
-
Continuous Runtime: Approximately 11 Hours
-
Net Weight: 115 kg
-
Dimensions: 740 × 530 × 635 mm
General Specifications
-
Brand: XMSJ
-
Series: YHS-ODH
-
Product Type: Open-Frame Diesel Generator
-
Rated Voltage: 220 V
-
Frequency: 50 Hz
-
Engine Speed: 3000 RPM
-
Power Factor: 1
-
Phase Options: Single Phase or Three Phase
-
Alternator Type: Self-Excited, Two-Pole Alternator
-
Starting System: Manual or Electric
-
Battery Included: No
-
DC Output: 12 V / 8.3 A
-
Engine Type: Single-Cylinder, Vertical, Four-Stroke Air-Cooled Diesel Engine
-
Combustion System: Direct Injection
-
Fuel Type: 0# or -10# Light Diesel
-
Fuel Consumption Rate: Approximately 295 g/kW/h
-
Noise Level: Approximately 80–85 dB at 7 Metres
-
Warranty: 12 Months
-
Country of Origin: China
Standard Features
Each generator includes or supports the following standard equipment:
-
Voltmeter
-
AC output socket
-
AC circuit breaker
-
Low-oil alert system
-
Open protective frame
-
Fuel tank
-
12 V DC output
Optional Features
Optional upgrades may include:
-
Electric starting system
-
Automatic transfer switch
-
Remote control
-
Four-wheel mobility kit
-
Digital multifunction meter
-
Customized voltage
-
Customized phase configuration
-
Custom branding
Optional components should only be included in the final listing when supplied with the selected configuration.
Suitable Applications
The XMSJ diesel generator range is suitable for:
-
Household emergency backup power
-
Farms and agricultural equipment
-
Workshops and garages
-
Construction sites
-
Commercial operations
-
Outdoor work areas
-
Remote locations
-
Lighting and compatible power tools
-
Temporary electricity supply
-
Small industrial equipment
Runtime and Fuel Consumption
The stated continuous runtime is based on manufacturer-supplied specifications. Actual runtime and fuel usage may vary depending on:
-
Connected electrical load
-
Generator model
-
Fuel quality
-
Environmental temperature
-
Maintenance condition
-
Engine speed
-
Operating conditions
Electric Start Information
Models configured with electric start require a compatible starting battery. The battery is not included unless separately specified.
Confirm the required battery voltage, capacity, size, and terminal arrangement before publishing or supplying an electric-start model.
Important Safety Information
Operate the generator outdoors only in a dry, well-ventilated area. Keep it away from doors, windows, garages, basements, tents, and enclosed workspaces.
Diesel exhaust contains carbon monoxide, which is invisible and potentially fatal. Follow the manufacturer’s instructions for grounding, ventilation, fuel handling, electrical connections, operation, and maintenance.
Select the correct model based on the total running wattage and starting wattage of all connected equipment.
