Sytong LM02-19LRF Infrared Thermal Imaging Sight Rifle Scope 256x192 Night Vision Monocular

Explore outdoor environments in darkness and challenging visibility conditions with the LM02-19LF Thermal Imaging Monocular. Designed for handheld observation, this compact thermal camera uses a 256 × 192 VOx sensor to display heat signatures in low light, nighttime, fog, and light rain.

The 19 mm objective lens provides a practical balance between field of view and viewing distance. Adjustable digital magnification allows users to examine distant subjects more closely, while the 50 fps frame rate supports smooth image movement during scanning and observation.

Its compact, shock-resistant housing measures 186 × 84 × 55 mm and weighs approximately 600 g, making it suitable for carrying during outdoor activities. The rechargeable lithium-ion battery supports portable use without requiring a permanent power connection.

Key Features

• Handheld thermal imaging monocular

• 256 × 192 thermal sensor

• 12 μm pixel pitch

• Thermal sensitivity of up to ≤30 mK

• Smooth 50 fps image refresh rate

• 19 mm objective lens

• Adjustable digital magnification

• Five brightness levels

• Shock-resistant construction

• Rechargeable lithium-ion battery

• Compact and lightweight design

• Suitable for nighttime and low-visibility observation

• One-year warranty

Product Specifications

• Model: LM02-19LF

• Product Type: Thermal Imaging Monocular

• Sensor Resolution: 256 × 192

• Sensor Type: VOx Thermal Sensor

• Pixel Pitch: 12 μm

• Thermal Sensitivity: ≤30 mK

• Objective Lens: 19 mm

• Magnification: Up to 8×

• Frame Rate: 50 fps

• Effective Viewing Distance: Up to 600 m, subject to environmental conditions

• Brightness Settings: Five Levels

• Battery Type: Rechargeable Lithium-Ion Battery

• Infrared Transmitter: Single Transmitter

• Product Dimensions: 186 × 84 × 55 mm

• Product Weight: Approximately 600 g

• Feature: Shock-Resistant

• Warranty: 1 Year

• Country of Origin: China

Thermal Observation Performance

The thermal sensor detects heat differences instead of relying on visible light. This allows the monocular to provide useful observation in conditions such as:

• Complete darkness

• Low-light environments

• Fog and mist

• Light rain

• Vegetated outdoor areas

• Changing temperature conditions

Actual detection and identification distances depend on the subject size, weather, temperature contrast, lens configuration, and surrounding environment.

Suitable Applications

This thermal imaging monocular may be used for lawful activities such as:

• Outdoor wildlife observation

• Property inspection

• Search and monitoring activities

• Nighttime navigation

• Camping and hiking

• Farm and livestock observation

• General thermal surveying

The compact LM02-19LF provides portable thermal viewing, adjustable magnification, and smooth image performance for outdoor and low-light observation.
