PARD TS31 Series Thermal Imager Scope Hunting Monocular 12µm LWIR Sensor 384*288 Resolution LEDS & IREA 800*800 Digital Camera

The PARD TS31/LRF Thermal Imaging Scope combines thermal detection, a high-resolution circular display, laser rangefinding, and digital recording features in a durable aluminium-alloy housing. Designed for outdoor observation and lawful sporting applications, it provides clear thermal imaging in low-light, nighttime, foggy, and visually challenging environments.

Its 384 × 288 thermal sensor uses a 12 μm pixel pitch to detect temperature differences and display detailed thermal images. The 800 × 800 IPS LCD provides a clear viewing experience, while multiple image modes allow users to adjust the display according to environmental conditions and personal preferences.

Available with 19 mm, 25 mm, 35 mm, or 45 mm objective lenses, the TS31/LRF offers different magnification and detection-distance options. The integrated laser rangefinder measures distances up to approximately 1000 metres or 1200 yards.

Key Features

• 384 × 288 thermal imaging resolution

• 12 μm thermal sensor

• 800 × 800 circular IPS display

• Integrated laser rangefinder

• Detection range of up to 1000 metres

• Multiple objective-lens options

• Multiple thermal colour modes

• Built-in photo and video recording

• Supports TF cards up to 128 GB

• IP67 weather-resistant construction

• Durable aluminium-alloy housing

• Approximately six hours of operating time

• Adjustable reticle colours

• Wi-Fi connectivity

• Rechargeable 18650 lithium-ion battery

Product Specifications

• Brand: PARD

• Model: TS31/LRF

• Product Type: Thermal Imaging Scope

• Thermal Resolution: 384 × 288

• Display Resolution: 800 × 800 pixels

• Display Type: IPS LCD

• Pixel Size: 12 × 12 μm

• NETD: 35 mK

• Frame Rate: 50 Hz

• Objective-Lens Options: 19 mm, 25 mm, 35 mm, or 45 mm

• Optical Magnification: 2×, 2.6×, 3.7×, or 4.7×

• Eye Relief: 100 mm

• Photo Resolution: 1536 × 1536 pixels

• Video Resolution: 768 × 768 pixels

• Storage: TF Card, up to 128 GB

• Laser Rangefinder: Up to 1000 m / 1200 yd

• Operating Time: Approximately 6 Hours

• Battery Type: Rechargeable 18650 Li-Ion Battery

• Protection Rating: IP67

• Housing Material: Aluminium Alloy

• Reticle Colours: Red, White, Yellow, and Green

Thermal Image Modes

The scope provides multiple display modes, including:

• White Hot

• Black Hot

• Red Hot

• Fusion 1

• Fusion 2

• Iron Red 1

• Iron Red 2

These modes help improve visibility and target distinction under different temperature and environmental conditions.

Detection Distance

Detection distance varies according to the selected objective lens:

• Human Detection: Approximately 800–1700 m

• Vehicle Detection: Approximately 1800–3000 m

Actual performance may vary based on weather, temperature, visibility, lens selection, and environmental conditions.

Select the appropriate lens size and configuration according to the required viewing distance and intended lawful application.
