    Mobile Generator Lighting T...

    Provide soft, wide-area illumination for construction sites, road maintenance, emergency work, outdoor events, warehouses, workshops, and temporary job locations with the YG LED Balloon Tower Light.

    The light uses a diffused balloon-style cover to distribute illumination in approximately 360 degrees, helping reduce harsh shadows and direct glare compared with conventional directional floodlights. Available power options range from 60W to 300W, with tripod and pole-mounting configurations for flexible temporary installation.

    The product is designed for AC operation and includes a built-in power supply, aluminium-alloy support structure, soft diffuser cover, selectable colour temperatures, dimming support, and listed IP65 environmental protection.

    Exact luminous output, input-voltage range, mounting accessories, dimming method, diffuser dimensions, weight, cable length, and IP-rating coverage should be confirmed for each selected model before publication.

    Key Features

    • 360-degree diffused light distribution

    • LED power options from 60W to 300W

    • Tripod and pole-mounting configurations

    • Soft balloon diffuser for reduced harsh shadows

    • Warm white, neutral white, and cool white options

    • Listed colour-temperature range from 2700K to 6500K

    • Colour-rendering index of Ra 80

    • Up to approximately 130 lm/W listed efficiency

    • Built-in LED power supply

    • Power factor above 0.95

    • Dimming support

    • IP65 environmental protection, subject to model confirmation

    • Aluminium-alloy structure with soft diffuser material

    • Operating temperature from approximately -40°C to 45°C

    • Listed 50,000-hour working life

    • Three-year warranty

    • Custom configurations available

    Product Specifications

    • Brand: YG, subject to final confirmation

    • Product Name: LED Balloon Tower Light

    • Product Type: Portable 360-Degree Diffused LED Work Light

    • Light Source: LED

    • Lamp Type: LED Balloon Lamp

    • Available Power Options: 60W, 80W, 100W, 150W, 200W, or 300W

    • Listed Luminous Efficiency: Approximately 130 lm/W

    • Listed Luminous Flux: Up to 360,000 lm, subject to verification

    • Beam Angle: Approximately 360°

    • Colour-Temperature Range: Approximately 2700K–6500K

    • Emitting Colours: Warm White, White, or Cool White

    • Colour Rendering Index: Ra 80

    • Driver: Built-In Power Supply

    • Input Voltage: Listed as 277VAC

    • Alternative Voltage Options: Confirm Before Publishing

    • Power Factor: Above 0.95

    • Power Source: AC

    • Dimming: Supported

    • Dimming Method: Confirm Before Publishing

    • Installation Options: Tripod Mounting or Pole Mounting

    • Tripod Included: Confirm Before Publishing

    • Pole Included: Confirm Before Publishing

    • Housing Material: Aluminium Alloy

    • Diffuser Material: Soft Fabric or Textile Cover

    • Ingress Protection: IP65, subject to component verification

    • Operating Temperature: Approximately -40°C to 45°C

    • Listed Service Life: Up to Approximately 50,000 Hours

    • Available Colour: White

    • Customization: Supported

    • Warranty: Three Years

    • Country of Origin: Henan, China

    Product-Type Clarification

    The product-specific data identifies this item as an LED Balloon Tower Light powered by AC electricity.

    The supplied description also includes general references to:

    • Diesel generators

    • Trailer-mounted towers

    • Solar power

    • Hydraulic masts

    • Self-loading lighting towers

    These references appear to describe a broader supplier product range rather than this specific balloon light.

    The final page should identify this product consistently as:

    • AC-powered LED balloon light

    • Tripod-mounted balloon work light

    • Pole-mounted balloon area light

    Do not describe it as diesel-powered unless the selected package includes a separate diesel generator.

    360-Degree Diffused Lighting

    The balloon-style diffuser distributes light around the installation point rather than concentrating it in one narrow direction.

    This design may provide:

    • Broad surrounding illumination

    • Reduced hard shadows

    • Lower direct glare

    • More even light distribution

    • Improved visibility around temporary work areas

    • Fewer dark areas between directional lamps

    The exact distribution pattern should be supported by a photometric report.

    Available Lamp Powers

    The product is listed in the following power options:

    • 60W

    • 80W

    • 100W

    • 150W

    • 200W

    • 300W

    Each wattage should have a separate SKU and clearly defined:

    • Luminous output

    • Diffuser size

    • Input current

    • Weight

    • Recommended mounting height

    • Illumination area

    • Cable requirements

    • Price

    Luminous-Flux Conflict

    The supplied data lists:

    • Luminous efficiency: approximately 130 lm/W

    • Total luminous flux: approximately 360,000 lm

    • Maximum lamp power: 300W

    At 130 lm/W, estimated raw output would be approximately:

    • 60W: 7,800 lm

    • 80W: 10,400 lm

    • 100W: 13,000 lm

    • 150W: 19,500 lm

    • 200W: 26,000 lm

    • 300W: 39,000 lm

    The listed 360,000-lumen figure is therefore inconsistent with the supplied wattages.

    Before publication, confirm whether 360,000 lm refers to:

    • A multi-light tower system

    • A different product

    • A peak calculated figure

    • A typographical error

    Do not publish 360,000 lm until supported by a test report.

    LED Efficiency

    The listed luminous efficiency is approximately 130 lm/W.

    Before publication, confirm whether this value represents:

    • Bare LED-chip efficiency

    • LED module efficiency

    • Complete lamp efficiency

    • Output before the diffuser

    • Output after diffuser losses

    A balloon diffuser may reduce measured delivered lumens while improving light uniformity.

    Colour Temperature

    The listed colour-temperature range is approximately 2700K to 6500K.

    This may represent either:

    • Separate fixed-CCT models

    • Selectable colour-temperature versions

    • Tunable-white lighting

    Before publication, clarify which option is supplied.

    Typical choices may include:

    • 2700K–3000K warm white

    • 4000K neutral white

    • 5000K daylight

    • 6000K–6500K cool white

    Colour Rendering

    The listed colour-rendering index is Ra 80.

    This may provide suitable general colour visibility for:

    • Construction work

    • Outdoor events

    • Warehouses

    • Maintenance

    • Emergency areas

    • Temporary workspaces

    Higher-CRI versions should only be listed if separately tested.

    277VAC Input

    The product is listed with a 277VAC input.

    This voltage is commonly used in certain commercial electrical systems.

    Before publication, confirm whether the product also supports:

    • 100–120VAC

    • 220–240VAC

    • 277VAC only

    • Universal 100–277VAC input

    • 50 Hz

    • 60 Hz

    The plug, cable, driver, and circuit protection must match the destination market.

    Built-In Power Supply

    The LED driver is listed as integrated into the product.

    Before publication, confirm:

    • Driver brand

    • Input-voltage range

    • Output voltage

    • Driver efficiency

    • Overvoltage protection

    • Overtemperature protection

    • Short-circuit protection

    • Surge protection

    • Replaceability

    • Dimming compatibility

    Power Factor

    The listed power factor is above 0.95.

    Before publication, verify:

    • Rated input voltage

    • Full-load condition

    • Dimming condition

    • Harmonic-distortion value

    • Driver test report

    Dimming Support

    The product supports dimming, but the control method is not supplied.

    Confirm whether dimming uses:

    • 0–10V

    • 1–10V

    • DALI

    • DMX

    • TRIAC

    • Remote control

    • Local rotary control

    • Stepped brightness levels

    Do not list every dimming protocol unless all are actually available.

    Balloon Diffuser

    The diffuser is described as soft cloth or fabric material.

    Before publication, confirm:

    • Diffuser diameter

    • Diffuser height

    • Fabric type

    • Flame-retardant rating

    • UV resistance

    • Tear resistance

    • Washability

    • Replacement availability

    • Inflation or structural method

    The product page should explain whether the diffuser requires an internal fan.

    Fan and Inflation System

    Some balloon lights use an internal fan to maintain the diffuser shape.

    Confirm whether this product includes:

    • Internal inflation fan

    • Fan power consumption

    • Fan noise level

    • Startup sequence

    • Replaceable filter

    • Automatic shutdown protection

    If the diffuser is mechanically supported rather than inflated, describe the structure accordingly.

    Tripod Mounting

    A tripod-mounted version may support fast temporary installation.

    Before publication, confirm:

    • Maximum tripod height

    • Minimum folded height

    • Tripod material

    • Leg spread

    • Weight capacity

    • Locking mechanism

    • Wind-speed limitation

    • Ground anchors

    • Carrying dimensions

    • Whether the tripod is included

    Pole Mounting

    The light may also be attached to a compatible pole.

    Confirm:

    • Required pole diameter

    • Clamp type

    • Maximum mounting height

    • Rotation capability

    • Included mounting hardware

    • Recommended wind conditions

    • Compatibility with existing mast systems

    Avoid claiming universal pole compatibility.

    IP65 Environmental Protection

    The listed IP65 rating may indicate:

    • Dust-tight protection

    • Resistance to low-pressure water jets

    Before publication, verify whether IP65 applies to:

    • LED module

    • Driver housing

    • Fan system

    • Electrical connector

    • Complete balloon assembly

    IP65 does not mean the product can be submerged.

    Operating Temperature

    The listed working range is approximately:

    • Minimum: -40°C

    • Maximum: 45°C

    Before publication, confirm:

    • Startup performance at -40°C

    • Driver derating above 40°C

    • Diffuser performance in cold conditions

    • Cable flexibility

    • Fan operation

    • Maximum humidity

    • Storage-temperature range

    Working Life

    The listed service life is approximately 50,000 hours.

    Before publication, confirm:

    • L70 or L80 rating

    • Ambient test temperature

    • Driver lifetime

    • Fan lifetime

    • Daily operating cycle

    • Diffuser replacement interval

    The diffuser, driver, fan, cable, and mounting hardware may have different service lives.

    Lighting Design Services

    Available project services may include:

    • Lighting and circuitry design

    • DIALux evo layouts

    • LitePro DLX layouts

    • AGi32 layouts

    • AutoCAD layouts

    • On-site light measurement

    • Installation support

    These services can help determine:

    • Number of lights required

    • Mounting height

    • Average lux level

    • Shadow control

    • Power requirements

    • Cable layout

    • Emergency coverage

    • Glare reduction

    Suitable Applications

    The LED balloon tower light may be suitable for:

    • Construction sites

    • Road repairs

    • Emergency response

    • Disaster-relief work

    • Outdoor events

    • Film and media production

    • Warehouse yards

    • Railway maintenance

    • Utility repairs

    • Industrial shutdowns

    • Temporary parking areas

    • Tents and temporary shelters

    • Remote maintenance work

    The selected wattage and mounting height should match the required illumination area and site conditions.

    Customization Options

    Available custom options may include:

    • Lamp power

    • Colour temperature

    • Input voltage

    • Dimming method

    • Tripod height

    • Pole adaptor

    • Diffuser size

    • Cable length

    • Plug type

    • Housing colour

    • Branding

    • Carrying case

    • Control system

    Each customized product should receive an approved technical specification before manufacture.

    Package Contents

    Depending on the selected configuration, the package may include:

    • LED balloon light head

    • Soft diffuser cover

    • Built-in LED driver

    • Tripod or pole adaptor

    • Power cable

    • Control switch

    • Carrying bag

    • Guy ropes or anchors

    • User manual

    Confirm whether the tripod, pole, dimmer, extension cable, and transport case are included or optional.

    Warranty

    The product includes a listed three-year warranty.

    Before publication, confirm coverage for:

    • LED chips

    • LED driver

    • Diffuser

    • Internal fan

    • Aluminium frame

    • Power cable

    • Dimming controller

    • Tripod

    • Mounting accessories

    • Labour

    • Return shipping

    Important Safety Information

    Install the light on firm, level ground and secure the tripod or pole before operation. Use guy lines or anchors where required.

    Maintain safe clearance from overhead electrical cables, structures, moving equipment, and combustible materials.

    Use weather-rated connectors and electrical protection suitable for the installation environment. Do not connect a 277V product to an incompatible power supply.

    Allow qualified personnel to perform electrical installation, driver replacement, cable repairs, and elevated mounting work.

    Translation missing: en.general.search.loading
