    MILESEEY TNV10 PRO 320×240 ...

    See heat signatures clearly in darkness, low light, fog, light vegetation, and challenging outdoor conditions with the MiLESEEY TNV10 Pro Thermal Imaging Monocular.

    The TNV10 Pro combines a 320 × 240 thermal detector, 12 μm pixel pitch, 50 Hz refresh rate, and an 800 × 600 OLED display to produce smooth, detailed thermal images for outdoor observation, camping, wildlife monitoring, property inspection, and general night-time use.

    Five viewing palettes, 4× digital zoom, hotspot tracking, enhanced UHD image processing, and one-handed controls make the device practical for fast field observation. Its 4500mAh rechargeable battery provides up to approximately 12 hours of operation under stated conditions.

    Key Features

    • 320 × 240 thermal sensor resolution

    • Advanced 12 μm infrared detector

    • Smooth 50 Hz image refresh rate

    • 800 × 600 OLED viewing display

    • Enhanced UHD image-processing mode

    • Five thermal colour palettes

    • Up to 4× digital zoom

    • Hotspot tracking

    • One-handed control layout

    • 4500mAh rechargeable battery

    • Up to approximately 12 hours of runtime

    • 30-minute and 60-minute automatic power-off options

    • IP65 dust and water resistance

    • Operating range from approximately -20°C to 60°C

    • Suitable for day and night thermal observation

    • Battery included

    Product Specifications

    • Brand: MiLESEEY

    • Model: TNV10 Pro

    • Product Type: Handheld Thermal Imaging Monocular

    • Thermal Sensor Resolution: 320 × 240 Pixels

    • Detector Pixel Pitch: 12 μm

    • Refresh Rate: 50 Hz

    • Display Type: OLED

    • Display Resolution: 800 × 600 Pixels

    • Digital Zoom: Up to 4×

    • Thermal Palettes: White Hot, Black Hot, Red Hot, Iron, and Jungle

    • Hotspot Tracking: Supported

    • Enhanced Image Mode: UHD Image-Processing Mode

    • Battery Capacity: 4500mAh

    • Battery Included: Yes

    • Listed Runtime: Up to Approximately 12 Hours

    • Automatic Power-Off: 30 or 60 Minutes

    • Protection Rating: IP65

    • Operating Temperature: Approximately -20°C to 60°C

    • Minimum Measurement Temperature: Confirm Before Publishing

    • Maximum Measurement Temperature: Confirm Before Publishing

    • Lens Focal Length: Confirm Before Publishing

    • Field of View: Confirm Before Publishing

    • Thermal Sensitivity: Confirm Before Publishing

    • Detection Distance: Confirm Before Publishing

    • Recognition Distance: Confirm Before Publishing

    • Image Recording: Confirm Before Publishing

    • Video Recording: Confirm Before Publishing

    • Internal Storage: Confirm Before Publishing

    • Charging Connection: Confirm Before Publishing

    • Dimensions: Confirm Before Publishing

    • Net Weight: Confirm Before Publishing

    • Mounting Compatibility: Confirm Before Publishing

    • High-Concern Chemicals: None Declared

    • Country of Origin: China

    • Warranty: Confirm Before Publishing

    320 × 240 Thermal Resolution

    The TNV10 Pro uses a 320 × 240 thermal detector to capture temperature differences within the observed scene.

    This resolution may provide clearer thermal detail for:

    • Outdoor observation

    • Wildlife monitoring

    • Camping

    • Property inspection

    • Search activities

    • Equipment checks

    • Night-time navigation

    • General heat-source detection

    Image quality also depends on lens specification, thermal sensitivity, atmospheric conditions, target size, distance, and temperature contrast.

    12 μm Infrared Detector

    The 12 μm detector pixel pitch supports a compact optical design while maintaining useful thermal image detail.

    Before publication, confirm:

    • Detector manufacturer

    • Spectral response range

    • NETD thermal sensitivity

    • Sensor calibration method

    • Non-uniformity correction

    • Shutter or shutterless operation

    Thermal sensitivity is particularly important when viewing objects with only small temperature differences.

    50 Hz Refresh Rate

    The listed 50 Hz refresh rate provides smoother image movement than lower-refresh thermal devices.

    This may help when:

    • Scanning outdoor areas

    • Following moving wildlife

    • Walking with the device

    • Panning across wide scenes

    • Observing moving equipment

    Actual performance may vary depending on image-processing mode and operating conditions.

    800 × 600 OLED Display

    The integrated OLED display has a listed resolution of 800 × 600 pixels.

    Potential advantages include:

    • Clear menu visibility

    • Good contrast

    • Smooth thermal-image presentation

    • Improved viewing in dark environments

    • Compact internal display design

    The display resolution is higher than the thermal sensor resolution because the device scales and processes the captured thermal image for viewing.

    UHD Image Mode

    The TNV10 Pro includes an enhanced UHD image-processing mode designed to improve visible detail in complex thermal scenes.

    This processing may help distinguish:

    • Grass

    • Brush

    • Water edges

    • Ground textures

    • Vegetation

    • Low-contrast heat signatures

    The supplied “50% more definition” statement should be used only if supported by a documented comparison method. A safer product claim is that UHD mode applies additional image enhancement to improve perceived detail.

    Five Thermal Palettes

    The device includes five viewing palettes.

    White Hot

    Warmer areas appear brighter while cooler areas appear darker.

    This mode may be suitable for general observation and simple heat-source identification.

    Black Hot

    Warmer areas appear darker while cooler areas appear brighter.

    Some users may find this mode comfortable for longer observation sessions.

    Red Hot

    The hottest parts of the scene are highlighted in red.

    This can make prominent heat sources easier to notice quickly.

    Iron

    The Iron palette displays temperature differences using multiple colours.

    It may help distinguish different heat levels across a scene.

    Jungle

    The Jungle palette is intended to improve visual separation in outdoor environments with vegetation and varied terrain.

    Palette performance depends on scene conditions and personal viewing preference.

    Hotspot Tracking

    Hotspot Tracking identifies and highlights the hottest area within the displayed scene.

    This feature may support:

    • Faster identification of strong heat sources

    • Outdoor scanning

    • Equipment inspection

    • Wildlife observation

    • Locating warmer objects in visually complex areas

    It should not be described as automatically identifying the type of object being viewed.

    4× Digital Zoom

    The TNV10 Pro provides digital magnification up to approximately 4×.

    Digital zoom enlarges the displayed image but does not increase the native thermal sensor resolution.

    At higher zoom levels:

    • Objects appear larger

    • Field of view becomes narrower

    • Fine detail may appear more pixelated

    • Hand movement may become more noticeable

    One-Handed Controls

    The control layout is designed for convenient one-handed operation.

    Before publication, confirm the available controls for:

    • Power

    • Zoom

    • Palette selection

    • Menu navigation

    • Image capture

    • Video recording

    • Brightness

    • Hotspot tracking

    • Automatic shutdown

    4500mAh Battery

    The device contains a listed 4500mAh rechargeable battery.

    The manufacturer states a runtime of up to approximately 12 hours.

    Actual runtime may depend on:

    • Display brightness

    • Environmental temperature

    • Digital zoom use

    • Recording features

    • Image-processing mode

    • Automatic shutdown settings

    • Battery age

    • Charging condition

    Before publication, confirm whether the battery is integrated or replaceable.

    Automatic Power-Off

    The device supports automatic shutdown after either:

    • 30 minutes

    • 60 minutes

    This feature can help conserve battery power when the device is left unused.

    Confirm whether the timer can also be disabled.

    IP65 Protection

    The TNV10 Pro carries a listed IP65 rating.

    This generally indicates:

    • Dust-tight enclosure protection

    • Resistance to low-pressure water jets under defined test conditions

    IP65 does not mean the device is designed for:

    • Submersion

    • Underwater use

    • High-pressure cleaning

    • Prolonged exposure to severe weather

    Keep charging ports and covers properly closed during outdoor use.

    Operating Temperature

    The stated operating range is approximately:

    • Minimum: -20°C

    • Maximum: 60°C

    Before publication, distinguish this from the thermal measurement range.

    The operating-temperature specification describes the environmental range in which the device is designed to function. It does not indicate the minimum or maximum temperature that the sensor can measure.

    Detection and Measurement Range

    The minimum and maximum temperature values are currently missing.

    Before publication, confirm whether the TNV10 Pro provides:

    • Temperature measurement

    • General thermal observation only

    • On-screen temperature readings

    • Centre-point measurement

    • Maximum-temperature measurement

    • Adjustable emissivity

    • Measurement accuracy specification

    Do not advertise precise temperature measurement unless the device supports calibrated measurement functions.

    Suitable Applications

    The MiLESEEY TNV10 Pro may be suitable for:

    • Camping

    • Wildlife observation

    • Outdoor exploration

    • Farm and property monitoring

    • Night-time navigation

    • Search activities

    • Building inspection

    • Electrical equipment checks

    • Heat-loss observation

    • General thermal imaging

    Do not use the device as a substitute for certified medical, firefighting, electrical-safety, or industrial measurement equipment.

    Package Contents

    Confirm whether the package includes:

    • MiLESEEY TNV10 Pro thermal monocular

    • Built-in or removable rechargeable battery

    • Charging cable

    • Power adapter

    • Protective carrying case

    • Lens cover

    • Wrist strap

    • Cleaning cloth

    • User manual

    Only verified accessories should be listed as included.

    Warranty

    The warranty period has not been supplied.

    Before publication, confirm coverage for:

    • Thermal detector

    • OLED display

    • Battery

    • Charging system

    • Buttons and controls

    • Housing

    • Software

    • Included accessories

    • Labour

    • Replacement shipping

    Important Usage Information

    Avoid pointing the thermal sensor directly toward extremely intense heat sources unless the manufacturer confirms this is safe.

    Protect the lens from impact, scratches, moisture, and contamination. Use only approved charging accessories and do not charge the device outside its specified temperature range.

    Thermal imaging detects heat differences and does not provide the same visual information as a standard daylight or colour night-vision camera.
