Customizable electric forklifts are available all electric forklifts are manufactured for indoor lifting operations

Improve pallet movement, light warehouse stacking, workshop transport, and compact material handling with this 0.8-Ton Three-Wheel Electric Forklift. Designed for manoeuvrability in confined spaces, the forklift combines a compact three-point support design, electric drive system, mechanical steering, and a maximum lifting height of approximately 2,000 mm.

The detailed configuration provides a rated lifting capacity of 800 kg and uses a 48V electrical system with a 1,500W brushless AC travel motor. Its compact dimensions make it suitable for selected warehouses, workshops, retail storage areas, small factories, and indoor logistics operations.

The model number TN-2.5E does not match the supplied 800 kg specifications. The exact model designation must be confirmed before publication.

Key Features

• 800 kg rated lifting capacity

• Compact three-wheel electric forklift

• Approximately 2,000 mm lifting height

• 1,500W brushless AC travel motor

• 48V electrical system

• 52Ah listed battery capacity

• Mechanical steering

• Battery-level display

• Approximately 4–6 hours of working time

• Approximately 6–8 hours of charging time

• Thickened one-piece steel body

• Suitable for narrow indoor spaces

• Custom colour options

• CE certification, subject to verification

Product Specifications

• Brand: Confirm Before Publishing

• Model: Confirm as 0.8T Model or TN-2.5E

• Product Type: Three-Wheel Electric Forklift

• Condition: New

• Operating Configuration: Three-Point Support

• Rated Lifting Capacity: 800 kg

• Maximum Lifting Height: Approximately 2,000 mm

• Overall Length Without Forks: Approximately 1,600 mm

• Overall Length With Forks: Approximately 2,520 mm

• Overall Width: Approximately 900 mm

• Overall Height: Approximately 1,700 mm

• Vehicle Weight: Approximately 850 kg

• Body Construction: Thickened One-Piece Stamped Steel Body

• Travel Motor: 1,500W Brushless AC Motor

• Controller: 24-Tube, 48V/60V Universal Controller

• Battery System: Four Battery Units

• Listed Battery Voltage: 48V

• Listed Battery Capacity: 52Ah

• Listed Battery Type: Dry Battery

• Lithium Battery Option: Confirm Before Publishing

• Charging Time: Approximately 6–8 Hours

• Continuous Working Time: Approximately 4–6 Hours

• Steering System: Mechanical Steering

• Battery Display: Included

• Maximum Listed Gradeability: Approximately 12°

• Colour: Customizable

• Certification: CE, subject to valid model documentation

• Terrain Suitability: Indoor Flooring and Suitable Smooth Outdoor Surfaces

• Warranty: Confirm Before Publishing

• Country of Origin: China

800 kg Lifting Capacity

This configuration is designed to lift loads up to 800 kg under the manufacturer’s approved load-centre, fork, mast, and floor conditions.

Actual safe lifting capacity may be reduced by:

• Increased load-centre distance

• Higher lift positions

• Extended forks

• Uneven loads

• Optional attachments

• Sloped surfaces

• Poor floor conditions

The final forklift data plate should show the verified lifting capacity and load centre.

Three-Wheel Compact Design

The three-point support design is intended to improve manoeuvrability in compact work areas.

It may be useful for:

• Narrow warehouse aisles

• Retail storage rooms

• Small workshops

• Light manufacturing areas

• Indoor loading spaces

• Compact distribution facilities

The exact turning radius should be confirmed before publishing.

Electric Drive System

The forklift uses a 1,500W brushless AC travel motor with a listed 48V electrical system.

Before publication, confirm:

• Drive-motor rated and peak power

• Lift-motor power

• Controller brand and model

• Maximum travel speed

• Loaded travel speed

• Braking system

• Regenerative braking capability

• Drive-wheel arrangement

Battery Configuration

The detailed table lists four 48V/52Ah dry batteries. This does not automatically confirm a lithium-ion battery system.

Before advertising lithium technology, verify:

• Battery chemistry

• Number of battery modules

• Nominal system voltage

• Total usable capacity

• Charger output

• Battery-management system

• Charging time

• Battery cycle life

• Battery warranty

If lithium and dry-battery versions are both available, they should be listed as separate variants.

Charging and Working Time

The detailed technical data lists:

• Charging Time: Approximately 6–8 hours

• Working Time: Approximately 4–6 hours

The separate claim of a full charge in 2–3 hours conflicts with these specifications. Only use a fast-charging claim for a verified lithium-battery configuration supplied with the correct charger.

Actual working duration depends on:

• Load weight

• Lifting frequency

• Travel distance

• Floor condition

• Driving speed

• Ambient temperature

• Battery age

• Operator behaviour

Lifting System

The forklift provides a listed maximum lift height of approximately 2,000 mm.

Before publishing, confirm:

• Mast type

• Number of mast stages

• Fork dimensions

• Minimum fork height

• Load centre

• Lift speed

• Lowering speed

• Free-lift height

• Lowered mast height

• Residual capacity at full height

Mechanical Steering

The compact 0.8-ton model uses mechanical steering. This provides a simple steering configuration for light-duty handling operations.

Confirm:

• Steering-wheel type

• Turning radius

• Steering angle

• Rear-wheel arrangement

• Steering effort under load

Body Construction

The forklift is described as using a thickened one-piece stamped steel body.

This construction is intended to provide:

• Structural stability

• Component protection

• Improved durability

• A compact industrial design

• Support for regular warehouse use

Exact steel grade and body thickness should only be stated when verified.

Gradeability

The listed climbing capability is approximately 12°. This figure should be verified under defined operating conditions.

Gradeability may vary according to:

• Loaded or unloaded operation

• Battery state

• Surface traction

• Ramp length

• Tyre type

• Fork position

• Load distribution

Do not operate on slopes above the verified manufacturer limit.

Suitable Applications

This compact electric forklift may be suitable for:

• Warehouses

• Workshops

• Retail storage

• Small manufacturing plants

• Food and beverage storage

• Building-material shops

• Farms

• Machinery-repair facilities

• Light industrial handling

• Indoor logistics

Outdoor use should be limited to surfaces approved for the forklift’s tyres, ground clearance, and electrical protection.

Related Capacity Models

The supplier also lists:

• 0.5-ton model

• 1.0-ton model

• 1.5-ton model

• 2.0-ton model

• 3.0-ton model

Each model has different dimensions, weight, motor power, battery capacity, steering system, and lifting height. They should be published as separate products or clearly defined variants.

Customization Options

Available customization may include:

• Body colour

• Battery type

• Battery capacity

• Charger type

• Fork dimensions

• Lift height

• Tyres

• Warning lights

• Horn

• Company logo

• Control panel

Each customized unit should receive a final technical specification sheet and accurate price.

Important Safety Information

Only trained and authorized operators should use the forklift. Never exceed the verified capacity shown on the final data plate.

Keep loads low while travelling and avoid sudden turns, unstable ground, and unverified slopes.

Inspect the forks, mast, battery, steering, brakes, tyres, controls, and warning devices before every shift.
