    1x-8xTU620 Infrared Night ...

    Observe heat signatures in complete darkness, low light, smoke, fog, and visually challenging environments with the TU620 Thermal Imaging Monocular. Featuring a 640 × 480 vanadium oxide detector, 12 μm pixel pitch, 25 mm F1.0 objective lens, and 50 Hz refresh rate, this portable thermal viewer is designed for outdoor observation, property inspection, wildlife monitoring, search support, and industrial maintenance.

    The TU620 provides approximately 1.4x base optical magnification with stepped digital zoom from 1x to 8x. Its wide 17.46° × 13.14° field of view supports broad-area scanning, while the listed battery system provides up to approximately ten hours of continuous operation.

    Key Features

    • 640 × 480 thermal detector

    • 12 μm pixel pitch

    • Vanadium oxide uncooled sensor

    • 8–14 μm spectral response

    • NETD of 30 mK or lower

    • 25 mm F1.0 objective lens

    • Approximately 1.4x base magnification

    • 1x to 8x digital zoom

    • 50 Hz refresh rate

    • Wide 17.46° × 13.14° field of view

    • Manual objective focusing

    • Up to approximately ten hours operating time

    • USB Type-C connectivity

    • Micro HDMI output

    • Optional Bluetooth remote control

    • Optional laser rangefinder

    • OEM, ODM, and OBM customization

    Product Specifications

    • Brand: Confirm Before Publishing

    • Model: TU620

    • Product Type: Thermal Imaging Monocular

    • Detector Type: Uncooled VOx Detector

    • Detector Resolution: 640 × 480 Pixels

    • Pixel Pitch: 12 μm

    • Spectral Range: Approximately 8–14 μm

    • Thermal Sensitivity: NETD ≤30 mK

    • Objective Lens: 25 mm

    • Lens Aperture: F1.0

    • Base Optical Magnification: Approximately 1.4x

    • Digital Zoom: 1x–8x

    • Field of View: Approximately 17.46° × 13.14°

    • Focus: Manual

    • Refresh Rate: 50 Hz

    • Display Type: Confirm Before Publishing

    • Display Resolution: Confirm Before Publishing

    • Operating Time: At Least Approximately 10 Hours

    • Battery Type: Custom Rechargeable Battery, subject to confirmation

    • Battery Capacity: Confirm Before Publishing

    • Charging Time: Confirm Before Publishing

    • Charging Interface: USB Type-C

    • Video Output: Micro HDMI

    • Wi-Fi: Confirm Before Publishing

    • Photo Recording: Confirm Before Publishing

    • Video Recording: Confirm Before Publishing

    • Internal Storage: Confirm Before Publishing

    • Waterproof Rating: Confirm Before Publishing

    • Operating Temperature: Confirm Before Publishing

    • Dimensions: Confirm Before Publishing

    • Weight: Confirm Before Publishing

    • Optional Remote Control: Bluetooth

    • Optional Laser Rangefinder: Available

    • Customization: OEM, ODM, and OBM

    • Warranty: One Year

    • Country of Origin: Shenzhen, China

    640 × 480 Thermal Detector

    The TU620 uses a 640 × 480 thermal detector with a 12 μm pixel pitch.

    This sensor configuration may support:

    • Detailed thermal images

    • Improved separation between nearby heat sources

    • Better image quality during digital zoom

    • Clearer observation of smaller thermal subjects

    • More usable detail at longer viewing distances

    Actual image performance depends on weather, atmospheric humidity, temperature contrast, focus, image processing, and display quality.

    Vanadium Oxide Sensor

    The detector uses uncooled vanadium oxide technology and operates within the listed 8–14 μm infrared spectral range.

    An uncooled detector supports:

    • Fast startup

    • Compact construction

    • Lower power consumption

    • Reduced mechanical complexity

    • Portable thermal observation

    NETD ≤30 mK

    The listed thermal sensitivity is 30 mK or lower.

    A lower NETD value generally indicates an improved ability to distinguish small temperature differences, which may provide clearer images in:

    • High humidity

    • Fog

    • Light rain

    • Low thermal contrast

    • Uniform backgrounds

    • Changing environmental conditions

    The exact test method, lens configuration, and processing mode should be confirmed.

    25 mm F1.0 Objective Lens

    The 25 mm F1.0 objective lens is designed to provide a relatively wide field of view for scanning and short- to medium-distance observation.

    It may be useful for:

    • Broad-area outdoor scanning

    • Property inspection

    • Wildlife observation

    • Search support

    • Equipment checks

    • Building inspection

    Detection and recognition ranges should be added only when supported by verified manufacturer test data.

    Base Magnification and Digital Zoom

    The TU620 provides approximately 1.4x base optical magnification with digital zoom from 1x to 8x.

    The zoom may be available in fixed steps such as:

    • 1x

    • 2x

    • 4x

    • 8x

    Digital zoom enlarges the displayed image but does not increase the detector’s native resolution. Fine detail may decrease at higher zoom levels.

    Wide Field of View

    The listed field of view is approximately:

    • Horizontal: 17.46°

    • Vertical: 13.14°

    This relatively wide view can help users locate heat sources and scan larger areas more efficiently.

    50 Hz Refresh Rate

    The 50 Hz refresh rate supports smooth thermal-image presentation during:

    • Handheld scanning

    • Walking observation

    • Subject tracking

    • Machinery inspection

    • Outdoor monitoring

    • Property checks

    Final image smoothness also depends on processor and display performance.

    Manual Focus

    The objective lens uses manual focusing.

    Manual focus allows the user to refine image clarity for different observation distances.

    The minimum focusing distance and focus-ring range should be confirmed before publication.

    Battery and Operating Time

    The device provides a listed operating duration of at least approximately ten hours.

    Before publication, confirm:

    • Battery chemistry

    • Battery capacity

    • Replaceable or built-in design

    • Number of included batteries

    • Charging time

    • Charger output

    • Low-temperature runtime

    • Battery warranty

    Actual runtime may vary according to display brightness, video output, recording, digital zoom, wireless accessories, and ambient temperature.

    USB Type-C Connection

    The included Type-C cable may support charging, data transfer, or both.

    Before publication, confirm:

    • Charging protocol

    • Data-transfer support

    • External power-bank compatibility

    • Charging while operating

    • Required charger wattage

    Micro HDMI Output

    A Micro HDMI cable is listed as standard equipment.

    This may allow the thermal image to be displayed on a compatible external screen or recording system.

    Confirm:

    • Output resolution

    • Output frame rate

    • Simultaneous internal-display operation

    • Audio support

    • Compatible cable type

    Optional Bluetooth Remote Control

    An optional Bluetooth remote control may allow selected device functions to be operated without directly pressing the monocular controls.

    Confirm:

    • Supported functions

    • Connection range

    • Battery type

    • Pairing procedure

    • Whether the remote is included or sold separately

    Optional Laser Rangefinder

    A laser rangefinder is listed as an optional accessory.

    Before publishing, confirm:

    • Maximum measurement range

    • Minimum measurement range

    • Accuracy

    • Laser classification

    • Measurement units

    • Single and continuous ranging modes

    • Whether distance data appears on the thermal display

    The rangefinder version should be listed as a separate product variant.

    Display System

    The internal display specifications are missing.

    Before publishing, confirm:

    • OLED, AMOLED, or LCOS technology

    • Display resolution

    • Display size

    • Brightness settings

    • Diopter adjustment

    • Eye relief

    • Contrast adjustment

    • Image sharpening

    • Noise reduction

    Display resolution should not be confused with detector resolution.

    Image Modes

    Confirm whether the monocular provides thermal palettes such as:

    • White Hot

    • Black Hot

    • Red Hot

    • Iron Red

    • Rainbow

    • Target Highlight

    • Edge Enhancement

    Only verified firmware features should be added to the final listing.

    Photo, Video, and Storage

    The supplier information does not confirm built-in recording.

    Before publication, verify:

    • Photo capture

    • Video recording

    • Photo resolution

    • Video resolution

    • Video frame rate

    • Internal storage capacity

    • Memory-card support

    • File formats

    • USB data transfer

    • Date and time stamping

    Environmental Protection

    The waterproof and dustproof rating has not been provided.

    Before advertising outdoor durability, confirm:

    • IP protection rating

    • Operating-temperature range

    • Storage-temperature range

    • Humidity limit

    • Drop resistance

    • Condensation protection

    • Port-cover sealing

    Standard Package

    The listed standard package may include:

    • TU620 thermal monocular

    • USB Type-C cable

    • Protective lens cap

    • 5V/2A power adapter

    • Region-compatible adapter plug

    • Rechargeable battery

    • Battery charger

    • Micro HDMI cable

    • Eye mask or eye cup

    • Two mounting clips

    • Quick-start guide

    The exact function, dimensions, and compatibility of the included mounting clips should be confirmed before publication.

    Optional Accessories

    Optional equipment may include:

    • Bluetooth remote control

    • Additional rechargeable battery

    • Desktop battery charger

    • Laser rangefinder

    • Carrying case

    • Protective strap

    • External display cable

    Optional items should not be shown as included with the standard package.

    Suitable Applications

    The TU620 may be suitable for:

    • Wildlife observation

    • Farm monitoring

    • Property inspection

    • Search and rescue support

    • Building heat-loss checks

    • Electrical inspection

    • Mechanical inspection

    • Night-time outdoor viewing

    • Security patrols

    • General heat-source detection

    Performance varies according to target size, thermal contrast, weather, environment, and device settings.

    Warranty and Support

    The listed warranty period is one year.

    Before publishing, confirm coverage for:

    • Thermal detector

    • Internal display

    • Battery

    • Charging port

    • HDMI output

    • Controls and buttons

    • Optional rangefinder

    • Waterproof sealing

    • Labour and shipping

    • Warranty exclusions

    Important Use Information

    Avoid pointing the thermal detector directly at the sun, welding arcs, lasers, or other intense energy sources, as these may damage the sensor.

    Keep the objective lens clean and dry, close all protective port covers before outdoor use, and store the device in protective packaging when not in operation.

    Follow all applicable privacy, observation, and local-use regulations.
