1.5 Ton Electric Forklift 1500kg Lithium Battery Forklift Truck with Charger for Warehouse Loading for Sale Customized

Improve pallet handling, warehouse stacking, loading, and industrial material transport with the YG CPD-30 Electric Counterbalance Forklift. Designed for seated operation, the reference model provides a rated lifting capacity of 3,000 kg and a standard lifting height of approximately 3,000 mm.

Its 80V lithium-ion battery system, 7,500W travel motor, hydraulic side shifter, and pneumatic tyres support material-handling operations across warehouses, manufacturing facilities, loading areas, and suitable outdoor paved surfaces.

The supplier also offers related CPD-20, CPD-25, and other capacity models. Each configuration should be published separately with its exact battery, dimensions, weight, motor power, turning radius, and price.

Key Features

• 3,000 kg rated lifting capacity

• 3,000 mm standard lift height

• 80V lithium-ion battery system

• 220Ah listed battery capacity

• 7,500W electric travel motor

• Seated operator configuration

• Two-stage mast

• Hydraulic side shifter

• Pneumatic industrial tyres

• Front-wheel-drive configuration

• Approximately 4–6 hours charging time

• Approximately 6–8 hours operating time

• LED safety lighting and wide-view mast options

• Suitable for indoor floors and outdoor pavement

• Custom battery, mast, tyre, fork, colour, and logo options

• 12-month main-component warranty

Product Specifications

• Brand: YG, subject to confirmation

• Model: CPD-30

• Product Type: Electric Counterbalance Forklift

• Condition: New

• Operating Mode: Seated Operation

• Rated Lifting Capacity: 3,000 kg

• Standard Lift Height: Approximately 3,000 mm

• Load Centre: 500 mm

• Power Source: Rechargeable Battery

• Battery Type: Lithium-Ion

• Battery Voltage: 80V

• Battery Capacity: 220Ah

• Stored Battery Energy: Approximately 17.6kWh, subject to usable-capacity confirmation

• Charging Time: Approximately 4–6 Hours

• Operating Time: Approximately 6–8 Hours

• Travel Motor Power: 7,500W

• Drive Type: Front-Wheel Drive

• Mast Type: Two-Stage Mast

• Mast Tilt: Confirm Forward and Rearward Angles

• Side Shifter: Hydraulic Side Shifter

• Fork Length: Approximately 1,070 mm

• Alternative Fork Length: Approximately 1,000 mm

• Fork Width: Approximately 100–120 mm, subject to selected fork

• Fork Thickness: Approximately 40 mm, subject to selected fork

• Standard Fork Dimensions: Approximately 1,070 × 120 × 40 mm

• Tyre Type: Pneumatic

• Wheelbase: Approximately 1,335 mm, subject to model verification

• Turning Radius: Approximately 2,365–2,450 mm

• Required Aisle Width: Approximately 3,800 mm

• Loaded Travel Speed: Approximately 12.5 km/h

• Unloaded Travel Speed: Approximately 14 km/h

• Overall Dimensions Without Forks: Approximately 2,700 × 1,200 × 2,200 mm

• Vehicle Weight: Approximately 3,700 kg

• Terrain Suitability: Indoor Flooring and Suitable Outdoor Pavement

• Colour: Customizable

• Warranty: 12 Months for Listed Main Components

• Country of Origin: China

Three-Ton Lifting Capacity

The CPD-30 is designed to lift loads up to 3,000 kg at a listed load centre of 500 mm.

Actual safe capacity may be reduced by:

• Increased load-centre distance

• Higher lift positions

• Longer forks

• Hydraulic attachments

• Uneven load distribution

• Slopes or unsuitable surfaces

• Non-standard mast configurations

The final capacity plate should show the verified rating for the exact mast, fork, battery, and side-shifter configuration.

80V Lithium Battery System

The reference configuration uses an 80V, 220Ah lithium-ion battery.

Before publishing, confirm:

• Battery chemistry

• Total and usable capacity

• Battery-management system

• Charger input voltage

• Charger output voltage and current

• Fast-charging capability

• Battery cycle-life rating

• Operating-temperature range

• Battery warranty

• Replacement-battery availability

The battery stores approximately 17.6kWh based on the listed voltage and capacity, although actual usable energy may be lower.

Charging and Working Time

The supplier lists:

• Charging Time: Approximately 4–6 hours

• Operating Time: Approximately 6–8 hours

Actual operating time depends on:

• Load weight

• Lifting frequency

• Travel distance

• Lift height

• Surface condition

• Driving speed

• Ambient temperature

• Battery condition

• Use of lights and attachments

Runtime should be advertised as approximate rather than guaranteed.

Two-Stage Mast

The standard two-stage mast provides a listed lifting height of approximately 3,000 mm.

Before publication, confirm:

• Lowered mast height

• Free-lift height

• Fully raised mast height

• Lift speed

• Lowering speed

• Mast visibility

• Residual capacity at maximum height

• Forward tilt angle

• Rearward tilt angle

Optional higher masts should be listed as separate configurations.

Hydraulic Side Shifter

The hydraulic side shifter allows the forks to move horizontally without repositioning the forklift.

This can improve pallet alignment during:

• Rack placement

• Truck loading

• Container handling

• Warehouse stacking

• Production-line supply

• Tight positioning tasks

The residual lifting capacity with the attachment installed should be displayed on the final data plate.

Fork Configuration

The reference forks are listed at approximately:

• 1,070 mm length

• 120 mm width

• 40 mm thickness

An alternative 1,000 mm fork length is also mentioned.

The specification “400 × 100 × 950” should be removed or clarified because it does not match the standard fork measurement format.

Pneumatic Tyres

Pneumatic tyres may offer improved traction and ride comfort on suitable paved outdoor surfaces.

They may be appropriate for:

• Loading yards

• Industrial pavement

• Warehouse entrances

• Smooth external routes

• Indoor production floors, subject to tyre type

Solid and non-marking tyre options should be listed separately when available.

Travel and Manoeuvrability

The reference performance includes:

• Loaded speed of approximately 12.5 km/h

• Unloaded speed of approximately 14 km/h

• Turning radius between approximately 2,365 and 2,450 mm

• Minimum working aisle width of approximately 3,800 mm

The final turning radius should be assigned to the exact CPD model.

Safety and Control Features

Depending on the final configuration, available features may include:

• Hill-start assistance

• Controlled descent

• LED headlights

• Rear work lights

• Warning beacon

• Reversing alarm

• Wide-view mast

• Large rear-view mirrors

• Battery-status display

• Emergency stop

• Overload warning

Only confirmed standard equipment should appear in the final package contents.

Available Capacity Models

Related models may include:

CPD-20

• Rated capacity: 2,000 kg

• Lift height: approximately 3,000 mm

• Travel motor: approximately 4,000W

• Weight: approximately 2,700 kg

• Dimensions without forks: approximately 2,300 × 1,200 × 2,200 mm

CPD-25

• Rated capacity: 2,500 kg

• Lift height: approximately 3,000 mm

• Travel motor: approximately 5,500W

• Weight: approximately 3,200 kg

• Dimensions without forks: approximately 2,500 × 1,200 × 2,200 mm

CPD-30

• Rated capacity: 3,000 kg

• Lift height: approximately 3,000 mm

• Travel motor: approximately 7,500W

• Weight: approximately 3,700 kg

• Dimensions without forks: approximately 2,700 × 1,200 × 2,200 mm

CPD-35 specifications should be confirmed before that model is advertised.

Suitable Applications

The YG CPD-30 may be suitable for:

• Warehouses

• Manufacturing plants

• Building-material stores

• Machinery-repair facilities

• Hotels

• Farms

• Food and beverage operations

• Retail distribution

• Construction-material handling

• Energy and mining support facilities

• Loading bays

• Outdoor paved industrial yards

Rough, muddy, loose, or steep terrain requires a forklift specifically designed and certified for that environment.

Customization Options

Available customization may include:

• Battery chemistry

• Battery capacity

• Charger specification

• Lift height

• Mast stages

• Fork dimensions

• Solid or pneumatic tyres

• Hydraulic attachments

• Body colour

• Company logo

• Operator cabin

• Warning lights

• Control panel

Each customized unit should receive a final approved technical specification sheet and accurate price.

Warranty and Support

The supplier lists a 12-month warranty for:

• Motor

• Controller

• Battery

• Hydraulic system

Confirm warranty terms, operating-hour limits, labour coverage, service location, maintenance requirements, and exclusions before publishing.

Delivery and Commissioning

Professional unloading and commissioning are recommended. Initial inspection should include:

• Battery and charger verification

• Fork alignment

• Mast and lift-chain inspection

• Hydraulic-system checks

• Side-shifter testing

• Steering and brake inspection

• Tyre inspection

• Lighting and alarm tests

• Capacity-plate verification

• Operator training

Important Safety Information

Only trained and authorized operators should use the forklift. Never exceed the rated capacity stated on the final data plate.

Keep loads low while travelling, avoid sudden turns, and operate only on approved surfaces and slopes.

Inspect the forks, mast, chains, battery, hydraulics, tyres, brakes, steering, lights, and warning devices before every shift.
